1956 AC Aceca-Bristol Specs

Specifications

Dimensions

Wheelbase:2286mm

Track/tread (rear):1270

Width:1550mm

Ground clearance:152

Kerb weight:965 kg

Track/tread (front):1270

Length:4064mm

Height:1321mm

fuel tank capacity:59.1 litres

Body Details

Body type:2 seater fixed-head coupé

Engine details

compression ratio:9:1

Catalytic converter:N

Engine layout:longitudinal

Top gear ratio:1

engine type:naturally aspirated petrol

Engine code:100D2

Capacity:2 litre1971 cc(120.278 cu in)

Bore/stroke ratio:0.69

Engine coolant:Water

Aspiration:Normal

Engine position:front

Gearbox:4

Final drive ratio:3.64

Engine manufacturer:Bristol

Cylinders:Straight 6

Bore × Stroke:66 × 96 mm, 2.6 × 3.78 in

Specific output(Net):63.4 bhp/litre1.04 bhp/cu in

Specific torque(Net):84.73 Nm/litre, 1.02 ft·lb/cu3

Performance

Acceleration 0-60mph:10.3 ss

Maximum speed:187 km/h (116 mph)mph

Weight-to-power ratio:10.35 kg/kW, 17.29 lb/bhp

maximum power output(Net):127 PS (125 bhp) (93 kW)at 6000 rpm

maximum torque(Net):167 Nm (123 ft·lb) (17 kgm)at 4500 rpm

Acceleration 0-80km/h (50mph):8 s

Standing quarter-mile:17.8 s

Power-to-weight ratio:131.33 PS/tonne (1000 kg), 96.59 kW/tonne (1000 kg), 129.53 bhp/tonne (1000 kg), 0.06 bhp/lb

Drive wheels:rear wheel drive

Our Sponsor

Fuel Consump.

Fuel system:3 So carbs

Chassis & Geomtry

turns lock-to-lock:2.000

Front suspension:I.TL.

Turning circle:10.40 m

Rear suspension:I.TL.

length:wheelbase ratio:1.78

Brakes

bmep (brake mean effective pressure):1064.7 kPa (154.4 psi)

Brakes F/R:Di/Dr

Other

Unitary capacity:328.5 cc

RAC rating:16.2

Number of doors:2

Valve gear:overhead valve (OHV), 2 valves per cylinder, 12 valves in total
