1986 AC Ace 2.0 Turbo Specs

Specifications

Dimensions

Wheelbase:2475mm

Track/tread (rear):1550

Width:1815mm

fuel tank capacity:65 litres

Track/tread (front):1600

Length:3960mm

Height:1170mm

Kerb weight:1020 kg

Body Details

Body type:2+2 seater fixed-head coupé

Engine details

compression ratio:8:1

Engine coolant:Water

Aspiration:Turbo

Catalytic converter:N

Engine layout:unknown

Torque split:34/66

Gearbox:5

Final drive ratio:3.62

Engine manufacturer:Ford

Capacity:2 litre1994 cc(121.681 cu in)

Bore/stroke ratio:1.18

Specific output(DIN):100.8 bhp/litre1.65 bhp/cu in

Specific torque(DIN):138.42 Nm/litre, 1.67 ft·lb/cu3

crankshaft bearings:5

Compressor:1 Garrett T3 turbocharger

Engine position:front

Top gear ratio:0.8

engine type:turbocharged petrol

Cylinders:Straight 4

Bore × Stroke:90.82 × 76.95 mm, 3.58 × 3.03 in

Performance

maximum power output(DIN):204 PS (201 bhp) (150 kW)at 6000 rpm

maximum torque(DIN):276 Nm (204 ft·lb) (28.1 kgm)at 4500 rpm

Weight-to-power ratio:6.81 kg/kW, 11.37 lb/bhp

Power-to-weight ratio:199.8 PS/tonne (1000 kg), 146.95 kW/tonne (1000 kg), 197.06 bhp/tonne (1000 kg), 0.09 bhp/lb

Drive wheels:all wheel drive

Our Sponsor

Fuel Consump.

Fuel system:Weber-Marelli fuel injection

Chassis & Geomtry

Rear suspension:I.STA.CS.

length:wheelbase ratio:1.6

Front suspension:I.

Brakes

bmep (brake mean effective pressure):1739.4 kPa (252.3 psi)

Front brake diameter:283 mm

Brakes F/R:VeDi/Di-S

Rear brake diameter:272 mm

Wheels & Tyres

Wheel size rear:7J x 16

Tyres rear:225/45 VR 16

Wheel size front:7J x 16

Tyres front:225/45 VR 16

Other

Unitary capacity:498.5 cc

Number of doors:2

RAC rating:20.5

Valve gear:single overhead camshaft (SOHC), 2 valves per cylinder, 8 valves in total
