1966 Aston Martin DBSC

Car Specs

1966 Aston Martin DBSC

Information

Aston Martin

Quick Facts

Production Total: 2

Chassis Code: Concept

Build Start: 1966

Available in other variants

read more »

Specifications

General

Build Start: 1966
Model Variant: Concept
Chassis Code: Concept

Dimensions

Track/tread (front): 1372mm
Length: 4451mm
Height: 1219mm
Kerb weight: 1293kg
Wheelbase: 2565mm
Track/tread (rear): 1359mm
Width: 1676mm
Fuel Tank Capacity: 88.6litres

Body Details

Body Type: 2 seater fixed-head coupé

Engine Details

Engine Type: naturally aspirated petrol
Cylinders: Straight 6
Bore × Stroke: 96 × 92mm
Compression Ratio: 8.9:1
Engine Coolant: Water
Aspiration: Normal
Engine Position: front
Engine Manufacturer: Aston Martin
Capacity: 4 litre (3996 cc)
Bore/stroke ratio: 1.04
Crankshaft Bearings: 7
Catalytic converter: N
Engine Layout: longitudinal
Gearbox: 5 speed manual

Our Sponsor

Performance

Power-to-weight ratio: 254.85 PS/tonne (1000 kg)
Drive Wheels: rear wheel drive
Weight-to-power ratio: 5.34kg/kW

Chassis & Geomtry

Length:Wheelbase Ratio: 1.74

Brakes

Brakes F/R: Di/Di-S

Other

Designer: Touring
Valve Gear: double overhead camshaft (DOHC), 2 valves per cylinder, 12 valves in total
Specific output(Gross): 81.3 bhp/litre1.33 bhp/cu in
Production Total: 2
Number of doors: 2
maximum power output(Gross): 330 PS (325 bhp) (242 kW)at 5750 rpm
maximum torque(Gross): at 4500 rpm
Unitary Capacity: 666cc
Steering: power assisted rack & pinion
RAC rating: 34.3
