1969 Aston Martin DB6 Mk II

Car Specs

1969 Aston Martin DB6 Mk II

Information

Aston Martin

Quick Facts

Build Start: 1969

Available in other variants

read more »

Specifications

General

Build Start: 1969
Model Variant: DB6

Dimensions

Wheelbase: 2584mm
Track/tread (rear): 1384mm
Width: 1676mm
Ground clearance: 158mm
Kerb weight: 1497kg
Track/tread (front): 1384mm
Length: 4623mm
Height: 1359mm
Fuel Tank Capacity: 86.4litres

Body Details

Body Type: 2+2 seater fixed-head coupé

Engine Details

Crankshaft Bearings: 7
Catalytic converter: N
Engine Position: front
Gearbox: 5 speed manual
Final Drive Ratio: 3.73
Engine Type: naturally aspirated petrol
Cylinders: Straight 6
Bore × Stroke: 96 × 92mm
Specific output(Net): 70.6 bhp/litre1.16 bhp/cu in
Specific torque(Net): 95.1 Nm/litre, 1.15 ft·lb/cu3
Compression Ratio: 8.9:1
Engine Coolant: Water
Aspiration: Normal
Engine Layout: longitudinal
Top Gear Ratio: 0.8
Engine Manufacturer: Aston Martin
Capacity: 4 litre (3996 cc)
Bore/stroke ratio: 1.04

Performance

Power-to-weight ratio: 191 PS/tonne (1000 kg)
Drive Wheels: rear wheel drive
Maximum Speed: 241km/h
Weight-to-power ratio: 7.12kg/kW
maximum power output(Net): 286 PS (282 bhp) (210 kW)at 5500 rpm
maximum torque(Net): 380 Nm (280 ft·lb) (38.8 kgm)at 4500 rpm

Our Sponsor

Fuel Consump.

Fuel system: 3 SU carbs

Chassis & Geomtry

Turns Lock-to-Lock: 3.250
Rear suspension: LA.TA.WL.CS.
Front Suspension: I.W.CS.ARB.
Length:Wheelbase Ratio: 1.79

Brakes

bmep (brake mean effective pressure): 1195kPa
Brakes F/R: Di/Di-S

Wheels & Tyres

Tyres Rear: 8.15-15
Tyres Front: 8.15-15

Other

Unitary Capacity: 666cc
Valve Gear: double overhead camshaft (DOHC), 2 valves per cylinder, 12 valves in total
Steering: power assisted rack & pinion
Number of doors: 2
RAC rating: 34.3
