1992 Subaru SVX

Car Specs

1992 Subaru SVX

Information

Subaru

Quick Facts

Build Start: 1992

Available in other variants

read more »

Specifications

General

Build Start: 1992
Model Variant: SVX

Dimensions

Track/tread (front): 1501mm
Length: 4625mm
Height: 1300mm
Wheelbase: 2610mm
Track/tread (rear): 1481mm
Width: 1770mm
Ground clearance: 135mm
Kerb weight: 1600kg
Fuel Tank Capacity: 70litres

Body Details

Body Type: 2+2 seater fixed-head coupé

Engine Details

Crankshaft Bearings: 7
Catalytic converter: Y
Engine Position: front
Engine Manufacturer: Subaru
Cylinders: Flat 6
Bore × Stroke: 96.9 × 75mm
Gearbox: 4 speed automatic
Final Drive Ratio: 3.70
Specific output(DIN): 68.4 bhp/litre1.12 bhp/cu in
Specific torque(DIN): 93.1 Nm/litre, 1.13 ft·lb/cu3
Engine Coolant: Water
Aspiration: Normal
Engine Layout: longitudinal
Torque Split: 35/65
Engine Type: naturally aspirated petrol
Engine Code: EJ33
Capacity: 3.3 litre (3319cc)
Bore/stroke ratio: 1.29
Top Gear Ratio: 0.69
Compression Ratio: 10.1:1

Performance

Acceleration 0-60mph: 8.7s
Standing quarter-mile: 16.7 s
Maximum Speed: 232km/h
Weight-to-power ratio: 9.45kg/kW
Drive Wheels: all wheel drive
Acceleration 0-80km/h (50mph): 6.4s
Acceleration 0-160km/h (100mph): 23.2s
Standing kilometre: 30.1 s
Power-to-weight ratio: 143.85 PS/tonne (1000 kg)
maximum power output(DIN): 230 PS (227 bhp) (169 kW)at 5600 rpm
maximum torque(DIN): 309 Nm (228 ft·lb) (31.5 kgm)at 4800 rpm

Our Sponsor

Fuel Consump.

Fuel system: MPFi
Fuel Consumption: 7.4/9.0/14.6 l/100km 90km/h / 120km/h / urban

Chassis & Geomtry

Length:Wheelbase Ratio: 1.77
Turning Circle: 10.80 m
Weight Distribution: 60% front
Rear suspension: I.MS.TrLi.TA.ARB.
Turns Lock-to-Lock: 3.100
Front Suspension: I.MS.CS.ARB.

Brakes

Front Brake Diameter: 302mm
Brakes F/R: VeDi/VeDi-S-ABS
Rear brake diameter: 290mm
bmep (brake mean effective pressure): 1169.9kPa

Wheels & Tyres

Wheel Size Rear: 16x7.5J
Tyres Rear: 225/50 ZR 16
Wheel Size Front: 16x7.5J
Tyres Front: 225/50 ZR 16

Aerodynamics

Drag coefficient: 0.29

Other

Unitary Capacity: 553.17cc
Designer: Giugiaro
Steering: power assisted rack & pinion
Valve Gear: double overhead camshaft (DOHC), 4 valves per cylinder, 24 valves in total
Number of doors: 2
RAC rating: 34.9
